Diesel Engine Tachometer - GE-1200 replacement


The durable GE-1400 makes taking rpm measurements on a 4- cycle diesel engine easy. Safe measurements with an accuracy of ± 1 rpm are as simple as clamping the detector to the fuel injection pipe.   CP detector sold separately required

  • Built-in memory function, 20 data (MAX) can be saved.
  • Three outouts- analog, monitor and pulse-provided as standard.
  • New larger LCD with backlight function.
  • Low battery warning indicator
  • Easy handling by just clamping the detector to the fuel injection pipe.
  • Improved sensitivity adjustment dial switch
  • Applicable to multi-injection pump types
  • Tripod or magnetic base mountable
  • Operates on four AAA batteries or optional AC Adapter power supply

SEND Inquiry


Description Hand-held diesel tachometer
Range 400 to 8,000 rpm
Detection Distance Contact (clamp on detector)
Display LCD 5 digit Display
Power / Battery life Four type AAA batteries provide 16 hrs. of continuous use.
Operating temperature 32° to 104° F / 0° to 40° C
Applicable Detectors CP-044 ( fuel injection pipe ) rotation sensor


includes: (AX-501) signal cable, four (4) AAA batteries, carrying case.

Please contact our Tech Sales dept for a possible demo unit trial, this unit is a special order and not returnable.
