DG-5100

English / Metric Comparator Display

DG-5100
DG-5100

New ! DG-5100 is a flexible display in which you may add and interchange functions. The DG-5100 is a high-resolution gauge counter having integrated structure. This counter achieves input frequency at 3 MHz which is high speed of ten times compared to conventional counter. The DG-5100 provides various calculation functions as standard such as condition memory, range (MAX value - MIN value) display, and offset value setting. Up to three optional cards can be installed in combination to add following five functions. 1. Analog output ( DG-0530 ) 2. BCD output ( DG-0522 ) 3. Comparator function ( TM-0340 ) 4. RS-232C output ( TM-0350 ) 5. DC power supply function ( TM-0301 )

  • "The required functions can be assembled by selecting and installing optional boards on rear panel such as BCD output, analog output and comparator output.
  • Engish / Metric switchable display
  • Compatible with all past (1978) to present Ono Sokki Gage Sensors.
  • Resolutions : 0.0004 in, 0.00004 in, 0.000004 in, 0.01mm, 0.001mm, 0.0001mm
  • RoHS Compliant

SEND Inquiry

Specifications

Output interchangeable function boards; comparator, RS-232C, Analog and BCD Output
Range 0 to ±9.99999" / ±99.9999" / 0 to / 0 to ±99.9999 / 0 to ±999.999/ 0 to ±9999.99 mm
Display Fluorescent display tube, 7 digits
Operating temperature 32 to +122°F / 0 to +50 °C
Power Supply 100 to 240 VAC
Weight Approx. 370 g
Dimensions 96(W)×48(H)×148(D)

Notes

DC power supply option TM-0301; DC 12~24 V ± 5 V
